MERTECH Q80 Receipt Printer (Ethernet, USB Black)

Name: MERTECH Q80 Receipt Printer (Ethernet, USB Black)
SKU: 1022
Availability: InStock

Product Code: 1022

Reviews: (0)

In Stock

$0.00

Specifications: (see all)

Audio and visual indication

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Overheating of the TPG, the presence of paper, lid opening, knife hanging

Check tape rewinding function

Yes

Colour

Black

The MERTECH Q80 receipt printer is suitable for any business. You can install it at the checkout counter in a retail or wholesale store, cafe or restaurant, hotel or gas station. The device prints cash receipts 58 and 80 mm wide. Fast receipt issuance speeds up queue movement.

Advantages of the model

The MERTECH Q80 uses thermal printing technology. To issue receipts, you only need a tape with a heat-sensitive layer. The material darkens upon contact with a hot printhead. Thermal printers are characterized by reduced dimensions. The technology makes it possible to print labels and images, including all popular barcodes. The device can print QR codes and excise stamps with PDF417 for the USAIS.

The desktop printer has a reliable mechanism. The thermal head resource is designed for 100 km of tape. The workflow is monitored by automatic sensors. Printing is accompanied by sounds and visual signals. The tape is replaced in 15 seconds using Easy Load technology. The menu has a fast-forward function.

The printer's design includes a cutting device. The operator can quickly and accurately cut the tape on a sharp blade. Receipts with an even cut-off line improve the impression of the service. The strength resource of the cutter is designed for 1.5 million slices.

Technical specifications

Characteristics of the MERTECH Q80 model:

Protocol for operation: ESC/POS.
The resolution of labels and barcodes is 203 dpi.
Information application speed: up to 230 mm/sec.
Working area width: up to 72 mm.
Built—in memory: 4 MB, RAM - 4 MB.
Interfaces: USB, RS232, Ethernet, RJ12 (for cash drawer).

The device is based on a sturdy steel frame. The exterior panels are made of plastic and polycarbonate. Reliable materials protect the mechanism and electronics from impacts, including falls. The warranty for thermal printers is valid for 2 years.

You can order receipt printers at the manufacturer's price on the MERTECH website. To place an order, leave a request on the website.

Audio and visual indication

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Overheating of the TPG, the presence of paper, lid opening, knife hanging

Check tape rewinding function

Yes

Colour

Black

EasyLoad

Yes

Equipment

Printer; Interface connection cables (RS232 and USB); Power supply; Warranty card; Packaging

External holder

Flash memory

4 Mb

Food

DC 24V, 1,5A

Gross weight

1.432 kg

Guarantee

2 years old

Interfaces

USB, Ethernet, RJ12 (Cash drawer)

Masterbox sizes

44x42x16 cm

Masterbox weight, kg

6.525 kg

Operating temperature

-0°C ~ +45°C

OS Support

Windows 7/8/10, Windows Server 2008/2012/2016, Linux, Javapos, OPOS, MacOS

Overall dimensions (WxDxH), mm

140*179*117

Package dimensions (1 pc.)

21x20x14 cm

Paper thickness, mm

0,056 - 0,13

Paper width, mm

58/80

Permissible humidity

5 - 95% (operation); 15 - 95% (storage)

Print head resource

100 km

Print resolution

203 dpi

Print speed

Up to 230 mm/sec

Print type

Direct thermal printing

Printer Class

Desktop

Printer frame Material

Metal

Printer Type

Receipt printer

Printing material

Receipt Feed

Printing protocol

ESC/POS

QR Code Printing

Yes

Quantity in the masterbox, pcs

4 pcs

RAM memory

4 Mb

Resistance to external influences

IP42

Roll diameter, mm

up to 83

Storage temperature

-20°C ~ +60°C

Supported 1D barcodes

UPC-A, UPC-E, Code 39, Code 93, Code128, EAN128, EAN8, EAN13, Interleaved 2 of 5

Supported 2D barcodes

QR Code; PDF417

Supported fonts

Chinese BIG-5, GB18030, Japanese S-JIS, Korean KS-X1001 Encodings -47

The cutter

Yes

The cutter's resource

1.5 million

USAIS support

Yes

Width of the printing area, mm

Up to 72
