The MERTECH V30E is an intelligent barcode scanner with navigation functions, specifically designed to work as part of AGV, AMR, and production lines. Thanks to deep learning algorithms and high sensitivity, it effectively recognizes barcodes and navigation tags even at high speeds and in difficult lighting conditions.
Configuration and features of the modification
The package includes a MERTECH V30E industrial scanner with a 3.1mm lens and an RS485 control cable for the V30E scanner. Cable number: 61ME.0359-A-02.
The MERTECH V30E (3.1mm) modification is equipped with autofocus and a CMOS Global Shutter scanning module. Such a module captures an image without distortion when an object moves, so the scanner is suitable for navigation, conveyor reading, and working with mobile robots.
The MERTECH V30E enclosure has an IP64 protection certificate. The scanner is protected from dust and water jets, so it is suitable for use in industrial premises, production lines and logistics areas.
Key Features of the MERTECH V30E
Intelligent decoding: neural network algorithms ensure high accuracy when reading corrupted and low-contrast codes.
High—frequency shooting: up to 120 frames/s, up to 120 codes/s, global shutter - optimal for moving objects.
Support for special codes: DataMatrix DM-12, DM-14 and their arrays are used in AGV navigation and marking of micro—components.
Wide field of view: up to 78°×69° with a 2.1mm lens, interchangeable optics for the task.
Vibration and motion resistance: stable operation at object speeds up to 3 m/s.
Technical specifications
Type of scanning module: CMOS Global Shutter.
Autofocus: yes.
The lens: 3.1 mm.
Sensor resolution: 1280*1080 pixels.
Frame rate: up to 120 Hz.
Working distance: about 100mm±5mm.
Viewing angle: 78°×69° with 2.1mm lens or 61.5°×53.5° with 3mm lens.
Dimensions: 68.3×60×40.8 mm.
Weight: about 180 g.
Backlight: white LEDs.
Interfaces: 100 Mbit/s Fast Ethernet, RS-485.
Protocols: TCP/IP, UDP.
Power supply: 24 V DC, up to 20 W with the backlight on.
Enclosure protection: IP64.
ESD: ±8 kV on contact, ±15 kV by air.
Operating temperature: 0...+50°C.
Storage temperature: -20...+70°C.
Humidity: up to 95% non-condensing.
Navigation features
The V30E is unique in that it combines the functions of a barcode scanner and a navigation sensor for mobile platforms.:
Reading navigation codes on floors, walls, containers and risers — building an AGV/AMR coordinate grid.
Working with DataMatrix DM-12 and DM-14 microcodes, including in the form of an array.
Optimization of driving routes and automatic positioning correction.
Integration into the logistics system via Ethernet or RS485.
Application areas
AGV/AMR navigation: a platform for orientation of mobile robots in warehouse and industrial premises.
Automotive Industry: Scanning of DPM codes on parts, metal surfaces and curved elements.
Electronics: reading micro-markings on boards, chips, and components.
Production lines: product passing control and code reading in motion.
Logistics: identification and sorting of parcels on automatic lines with the participation of robots.
Medicine: reading codes on test tubes, packages, and equipment at high flow density.
The MERTECH V30E is a new generation intelligent scanner that combines the capabilities of an industrial decoder and a navigation sensor. It is suitable for robotic logistics systems, flexible production lines and projects where high speed, precision and compactness are important.
Areas of application
For Marking, For Honest Mark, Industrial
Barcode sensitivity
Tilt ± 65° / 360° Rotation / Deviation ± 60 °
Body material
Metal (aluminum alloy)
Colour
Black and White (Mono)
Connection type
Wired
Drop test
It can withstand a fall from a height of 1 m.
Equipment
Scanner, Warranty Card, Quick Start Guide, Main RS-232 cable other cable type (optional)
