Thermal Transfer Label Printer MERTECH G400 Ethernet, USB, RS-232

Name: Thermal Transfer Label Printer MERTECH G400 Ethernet, USB, RS-232
SKU: 4605
Availability: InStock

Product Code: 4605

Reviews: (0)

In Stock

$0.00

Specifications: (see all)

Audio and visual indication

Yes

Bartender Support

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Paper availability, Ribbon availability, Lid opening, Label Gap, Printhead Temperature, Black Marks, Tape Termination, Engine Overheating temperature

Colour

Black, Grey

The MERTECH G400 thermal transfer label printer belongs to the industrial class. Up to 30,000 labels can be printed on it per day. The model is suitable for labeling goods in retail and small wholesale trade. It can print labels for marketplaces, stamps for Honest Sign and USAIS, as well as cash receipts.

Advantages of the model

The thermal transfer printer has a reliable design. The thermal head will not fail during the printing of 50 km of labels. The safety of work is controlled by a system of 8 sensors. A convenient control panel with a display is installed on the case.

When choosing templates, you can use a large number of fonts. The thermal transfer printer prints a large number of 1D and 2D barcodes, including PDF417, Data Matrix and QR codes. Customers get access to the Bartender program to customize the design of labels and receipts.

The model supports a wide range of printing protocols and interfaces. The basic configuration includes connection to a computer via USB Type B, RS-232, Ethernet and USB HOST. Optionally, a Wi-Fi connection is available.

The device has a stylish body with grey and black panels. Through the transparent insert, you can observe the work process. The rolls are replaced using the Easy Load system and take no more than 15 seconds.

Specifications

The main parameters of the MERTECH G400 model:

Support for TSPL and ZPL protocols.
Working speed: up to 355 mm/sec.
Resolution: 203 DPI.
The length of the application area: 15-2286 mm.
The width of the application area: up to 104 mm.
Flash memory: 32 MB
RAM memory: 128 MB
Case dimensions: 460 x 263 x 330 mm.
Device weight: 12.5 kg.
The warranty is valid for 2 years.

A 25-120 mm wide label tape is suitable for printing. Rolls with a winding length of up to 450 m and a diameter of up to 254 mm are placed in the mechanism. The device prints on sticky labels, on tapes made of paper, textiles, and synthetic materials. Ribbons made of wax, resin, or a mixture of components are suitable as consumables.

The package may include a cutter and an external roll holder. The cutter's knife will stay sharp for 1 million uses. Printer accessories are sold separately. To discuss the terms of the order and buy the equipment at a low price, leave a request on the website.

Audio and visual indication

Yes

Bartender Support

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Paper availability, Ribbon availability, Lid opening, Label Gap, Printhead Temperature, Black Marks, Tape Termination, Engine Overheating temperature

Colour

Black, Grey

Diameter of the roll sleeve

1.5 inches (38.1 mm), 3 inches (76.2 mm)

Diameter of the sleeve, mm

25.4 (1 inch)

EasyLoad

Yes

Equipment

Printer, Interface connection cables (RS232 and USB), Power supply, CD with instructions and software, Warranty card, Packaging

External holder

Yes (optional)

Flash memory

32 Mb

Food

AC 220V, 50Hz

Gross weight

16.2 kg

Guarantee

2 years old

Interface

USB Type B, RS-232, Ethernet, USB HOST, Wi-Fi — optional

Label Separator

Yes (optional)

Length of the printing area, mm

15 - 2286

Operating temperature

5 ~ 40°C

OS Support

Windows 2000, Vista, 7, 8, 10, 11, IOS

Overall dimensions (WxDxH), mm

460x263x330

Package dimensions (1 pc.)

61.5x50x41.5 cm

Paper thickness, mm

0.08 - 0.25 (76 microns - 250 microns)

Paper width, mm

25-120

Permissible humidity

30 - 85% (operation); 10 - 90% (storage)

Print resolution

203 dpi

Print speed

Up to 152 mm/sec

Print type

Thermal transfer

Print width, mm

104

Printer Class

Industrial

Printer frame Material

Metal

Printing material

Paper, textile and synthetic tapes, labels

Printing protocol

TSPL, ZPL

QR Code Printing

Yes

RAM memory

128 Mb

Recommended print volume per day

30,000 labels

Ribbon band width (min/max), mm

25-120

Ribbon roll winding length

450 mm (600 mm optional)

Ribbon sleeve diameter

25.4 mm (1 inch)

Ribbon type

Wax-based; wax- and resin-based; resin-based

Ribbon winding

OUT

Roll diameter, mm

Up to 250 (up to 10 inches)

Roll winding length, m

450

Software compatibility

GBS.Market, Service+, Triar, Labeling.Simply

Storage temperature

-20°C ~ +50°C

Supported 1D barcodes

Code 39, Code 93, EAN 8/13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5 , Logmars, Code 11, Code 49, Cadablock

Supported 2D barcodes

PDF417, Data matrix code, Maxi Code, QR code, Micro PDF417, Micro QR code, Aztec code

Supported code pages

PC437, 720, 737, 755, 775, 850, 852, 855, 856, 857, 858, 860, 862, 863, 864, 865, 866; Windows1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257, 1258; ISO8859-1, 2, 3, 4, 5, 6, 8, 9, 15; DBCS 932 (JIS), 936(GBK), 949 (Koran), 950(BIG5)

Tape rewinding function

Yes

The ability to download fonts

Yes

The cutter

Yes (optional)

The cutter's resource

1 million

Thermal head resource

50 km

USAIS support

Yes

Weight

12.5 kg

Width of the tape (min/max), mm

30 - 110
