MERTECH G400 Thermal Transfer Label Printer (300 DPI) Ethernet, USB, RS-232

Name: MERTECH G400 Thermal Transfer Label Printer (300 DPI) Ethernet, USB, RS-232
SKU: 4698
Availability: InStock

Product Code: 4698

Reviews: (0)

In Stock

$0.00

Specifications: (see all)

Audio and visual indication

Yes

Bartender Support

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Paper availability, Ribbon availability, Lid opening, Label Gap, Printhead Temperature, Black Marks, Tape Termination, Engine Overheating temperature

Colour

Black, Grey

The MERTECH G400 thermal transfer printer is suitable for printing labels and receipts. The industrial-grade model prints up to 30,000 labels per day. You can use the printer to print the USAIS excise stamps and the "Honest MARK" marking codes, to make deliveries to marketplaces.

Advantages of the model

The industrial-grade printer has a reliable design. The thermal head's safety margin is designed for 50 km of receipts or labels. 8 sensors are responsible for the stable operation of the printing mechanism. You can control the settings using a convenient panel with a display.

The MERTECH G40 supports a large number of page codes, fonts, and barcodes. When printing, you can use PDF417, Data Matrix, QR. The 300 DPI resolution allows you to print small text. You can manage printing templates in the free Bartender program.

Wired and wireless interfaces are used to connect to the computer. The basic configuration includes support for USB Type B, RS-232, Ethernet and USB HOST. Optionally, a Wi-Fi connection is available.

The printer has a modern design with black and grey panels. A transparent window is made on the case to monitor the operation of the mechanism and control the remaining tape winding. The technology takes no more than 15 seconds to replace the rolls.

Technical specifications

Characteristics of the MERTECH G400 model (300 DPI):

Protocols: TSPL, ZPL.
Working speed: up to 203.2 mm/sec.
Image resolution: 300 DPI.
Working area length: 15-2286 mm.
Working area width: up to 104 mm.
Flash memory: 32 MB
RAM memory: 128 MB
Case dimensions: 460 x 263 x 330 mm.
Device weight: 12.5 kg.
The warranty is 2 years.

The machine prints on sticky labels and tapes made of paper, textiles or synthetic materials. Suitable tape width: from 25 to 120 mm. The compartment size is designed for rolls with a diameter of up to 254 mm and a winding of up to 450 m. The printing mechanism is compatible with ribbons made of wax, resin or a mixed composition.

As accessories, you can order an external roll holder and a cutter. The blade will stay sharp for 1 million uses. To discuss the terms of the order and buy printers at a low price, leave a request on the website.

Audio and visual indication

Yes

Bartender Support

Yes

Body material

ABC + PC (plastic + polycarbonate)

Built-in sensors

Paper availability, Ribbon availability, Lid opening, Label Gap, Printhead Temperature, Black Marks, Tape Termination, Engine Overheating temperature

Colour

Black, Grey

Diameter of the roll sleeve

1.5 inches (38.1 mm), 3 inches (76.2 mm)

Diameter of the sleeve, mm

25.4 (1 inch)

EasyLoad

Yes

Equipment

Printer, Interface connection cables (RS232 and USB), Power supply, CD with instructions and software, Warranty card, Packaging

External holder

Yes (optional)

Flash memory

32 Mb

Food

AC 220V, 50Hz

Gross weight

16.327 kg

Guarantee

2 years old

Interface

USB Type B, RS-232, Ethernet, USB HOST, Wi-Fi — optional

Label Separator

Yes (optional)

Length of the printing area, mm

15 - 2286

Operating temperature

5 ~ 40°C

OS Support

Windows 2000, Vista, 7, 8, 10, 11, IOS

Overall dimensions (WxDxH), mm

460x263x330

Package dimensions (1 pc.)

61.5x50x41.5 cm

Paper thickness, mm

0.08 - 0.25 (76 microns - 250 microns)

Paper width, mm

25-120

Permissible humidity

30 - 85% (operation); 10 - 90% (storage)

Print resolution

300 dpi

Print speed

Up to 152 mm/sec

Print type

Thermal transfer

Print width, mm

104

Printer Class

Industrial

Printer frame Material

Metal

Printing material

Paper, textile and synthetic tapes, labels

Printing protocol

TSPL, ZPL

QR Code Printing

Yes

RAM memory

128 Mb

Recommended print volume per day

30,000 labels

Ribbon band width (min/max), mm

25-120

Ribbon roll winding length

450 mm (600 mm optional)

Ribbon sleeve diameter

25.4 mm (1 inch)

Ribbon type

Wax-based; wax- and resin-based; resin-based

Ribbon winding

OUT

Roll diameter, mm

Up to 250 (up to 10 inches)

Roll winding length, m

450

Software compatibility

GBS.Market, Service+, Triar, Labeling.Simply

Storage temperature

-20°C ~ +50°C

Supported 1D barcodes

Code 39, Code 93, EAN 8/13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5 , Logmars, Code 11, Code 49, Cadablock

Supported 2D barcodes

PDF417, Data matrix code, Maxi Code, QR code, Micro PDF417, Micro QR code, Aztec code

Supported code pages

PC437, 720, 737, 755, 775, 850, 852, 855, 856, 857, 858, 860, 862, 863, 864, 865, 866; Windows1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257, 1258; ISO8859-1, 2, 3, 4, 5, 6, 8, 9, 15; DBCS 932 (JIS), 936(GBK), 949 (Koran), 950(BIG5)

Tape rewinding function

Yes

The ability to download fonts

Yes

The cutter

Yes (optional)

The cutter's resource

1 million

Thermal head resource

50 km

USAIS support

Yes

Weight

12.5 kg

Width of the tape (min/max), mm

30 - 110
