Banknote counter with authenticity detector MERTECH C-120 DOUBLE CIS MG touch screen

The MERTECH C-120 DOUBLE CIS MG touch screen banknote counter is a high—quality cash counting device with an authentication function. This office counter is equipped with the latest technologies for detecting counterfeit banknotes, including magnetic tags, spectral analysis of paint, double CIS verification of the banknote image and other advanced techniques. This makes the meter ideal for businesses that require reliability and speed when working with cash.

Design features

The MERTECH C-120 DOUBLE CIS MG touch screen counter provides fast and accurate banknote processing with automatic recalculation mode. The device supports several modes for working with cash:

• Simple recalculation;
• Automatic recalculation;
• Definition of denominations;
• Summation mode;
• Sorting;
• Packaging.

The counter can work with various currencies, including the Russian ruble, the US dollar, the euro, as well as the currencies of several other countries. The conversion rate is adjustable and varies from 800 to 1,500 banknotes per minute, depending on the selected mode.

Authenticity Detector

The MERTECH C-120 model is equipped with multifunctional authenticity detectors. The banknotes are checked using 8 detections:

• Checking magnetic tags;
• Spectral analysis of paint;
• Double CIS checking the banknote image;
• Infrared detection;
• Ultraviolet detection;
• Double check;
• RGB and geometric control of the banknote.

These technologies make it possible to detect counterfeit banknotes with high accuracy and eliminate errors during recalculation.

Display and control

The MERTECH C-120 is equipped with a 4.5-inch TFT LCD display with a resolution of 854x480, which displays information about the result of the calculation, errors and current settings. The device has a touch control and a keypad for user convenience. You can also connect a remote display to display the results on an external screen.

Advantages of the model

• High conversion rate: up to 1,500 banknotes per minute.
• The counter is equipped with a dual CIS analysis system for the front and back sides of banknotes
• Multifunctional authenticity detectors: 8 types of banknote checks, including magnetic and ultraviolet tags.
• Multi-currency support: suitable for working with rubles, dollars, euros and many other currencies.
• User-friendly display: 4.5" touch screen with the ability to adjust various modes.
• Packing and sorting modes: the ability to quickly and accurately pack and sort banknotes by face value.
• Compact and reliable: housing made of durable plastic, protection class IP42, resistant to falls.

Technical specifications

• Loading tray capacity: 500 banknotes.
• Receiving tray capacity: 200 banknotes.
• Checking speed: 800, 1000, 1200, 1500 banknotes per minute.
• Loading method: Horizontal.
• Noise level: up to 85dB.
• Packing mode: Yes, with a packing size from 1 to 1000 banknotes.
• Display type: LCD, 4.5" TFT with 854x480 resolution.
• Control: Touch and push-button
• Power supply: AC 100-240V 50/60Hz.
• Warranty: 2 years.

Conclusion

The MERTECH C-120 DOUBLE CIS MG touch screen banknote counter is a reliable and efficient solution for anyone who values accuracy, speed and security when processing cash. It is ideal for use in offices, at cash registers, as well as in institutions where it is important to quickly and safely recalculate banknotes of different currencies.
