MERTECH CD-TFT customer display

Product Code: 1114
Reviews: (0)
In Stock
$142.00
Buy in one click
Specifications: (see all)
Adjustable Stand Height
Yes
Admissible humidity
0% ~ 95%
Body Material
ABC + PC (plastic + polycarbonate)
Brightness
400 cd/m2
Changeable Tilt Angle
Yes, 45°

The MERTECH CD-TFT display allows customers to monitor all cash operations. Such devices can work on any platform, which confirms their versatility. Such a display can fit in absolutely any POS - system, providing a comfortable work of cashiers and customers control over purchases.

The customer display is an important element, which largely determines the first impressions of customers about the store (or other organization). Therefore, it makes sense to equip your business with quality equipment. This model has a fairly wide list of advantages:

  • The chromaticity of 24 bits. This is not the highest figure, but the needs of the display for the buyer it more than satisfies. In addition, this color scheme provides maximum system performance.
  • CD-TFT display is one of the most stable devices in its segment.
  • Compactness. This model has a small size - the diagonal of the display is only 7 inches. This allows you to fit it into a cash register system of any size. This indicator will be in the spirit of the owners of small stores, where every square centimeter is worth its weight in gold.
  • Optional screensaver mode. Such a program automatically activates screen blanking. The use of such functions has many positive aspects: reducing the level of equipment wear and tear, reducing power consumption by reducing productivity, etc. Thus, the CD-TFT, as well as other devices using similar firmware, lasts much longer, and saves energy

The CD-TFT is a multifunctional customer display that will delight you with its ergonomics. Compact size together with strict size allows you to place such a device in any store or sales room. It should also be noted the high quality of materials used for the housing. The material has high wear resistance, providing a long service life.

Note: The LCD panel has a full protective coating against moisture, scratches and dirt. Therefore, even in constant use it will not lose its presentable appearance.

The developers made sure that the owners of such systems do not have to spend a lot of time cleaning the display. But if the panel does get dirty, there is no need to buy expensive tools to clean it. It will be enough to use an ordinary napkin, which is used to collect dust. The lack of distance between the frame and the display will prevent the entry of various contaminants. This problem of many contact devices, has been completely solved in the CD-TFT.

All in all, it is a compact and at the same time functional model, which is suitable for the equipment of any commercial enterprise.

Housing
Overall dimensions (WxDxH), mm
185x112x410
Memory
MS card
Optional
NAND Flash
128 Mb
SD card
Optional
Interfaces
Interface
USB HID; USB-COM - emulation
Interfaces
USB HID; USB-COM - emulation
Body
Body Material
ABC + PC (plastic + polycarbonate)
Color
Black
Operation parameters
Power
5V/300mA
Storage temperature
-40°C ~ +70°C
Functionality
Adjustable Stand Height
Yes
Changeable Tilt Angle
Yes, 45°
Display Rotation
Yes, 90°
Supported images
JPEG, BMP, PNG
Supported protocols
ESC/POS, CD5220
Performance parameters
Resistance to external influences
IP42
Operating parameters
Admissible humidity
0% ~ 95%
Operating temperature
0°С ~ +50°С
Options
Packages
Customer Display, Driver Disc, Warranty Card, Packaging
Display
Brightness
400 cd/m2
Diagonal
7
Display type
TFT
Resolution
800x480px
Function parameters
External power adapter
Optional, 5V/2A
