Wired Barcode Scanner MERTECH 610 P2D SuperLead USB Black

Product Code: 4830
Reviews: (0)
In Stock
$51.00
Buy in one click
Specifications: (see all)
13 MIL
40-170 mm
5 MIL
30-90 mm
Analogues of manufacturers
datalogic; honeywell; Zebra; Newland; CipherLab
Application areas
For 1C, For alcohol, For marking, For a pharmacy, For perfumes, For EGAIS, For a store, For marking shoes, For cigarettes, For a warehouse, For an honest sign, For EVOTOR, Industrial
Auto Scan
Yes

The MERTECH 610 P2D is a wired scanner that recognizes all barcodes created: both linear (1D) and two-dimensional (2D). The barcodes are scanned with the improved Superlead technology.

Specifications

The housing of the device is made of plastic and polycarbonate. Rugged housing protects the electronics. Multiple falls from a height of 150 cm do not affect the operation of the device. Ergonomic device fits comfortably in the hand of the operator.

Scanning conditions:

  • Speed: 100 scans/sec.
  • Camera resolution: 640x480 pixels.
  • Illumination technology: LED 3500K Antireflect®.
  • Angle of coverage: 40x32 degrees.
  • Reading range: from 30 mm.
  • Reading resolution: 3.9 MIL.
  • Encoding contrast: 20% and higher.

The model was designed taking into account the requirements of the "Honest Sign" system. It is suitable for the registration of any labeled goods, for the registration of alcoholic products for the EGAIS.

Device resistance class: IP 54. The temperature of use: fro m-20C to +50C. The main interface USB-HID is used to connect to a cash register or POS system.

Advantages of new generation scanners

In the model MERTECH 610 P2D a new version of SUPERLEAD technology is implemented. It has improved the recognition of non-standard size codes: small or large. Reading is carried out at any angle of inclination. The new version of SUPERLEAD also increased the distance for scanning labels.

The reader is equipped with Antireflect glare protection. This technology avoids glare when scanning barcodes. Antireflect technology works when scanning from any surface (metal, glass, plastic packaging, clear film, etc.).

We made the sight brighter and more contrasting for accurate aiming of the scanner. The updated scope will be visible in any lighting conditions.

Buy bar code scanners

In the Internet-shop MERTECH you can buy bar code scanners at manufacturer's price. Delivery of equipment is carried out in all regions of your country. Leave your request online, and then we will choose the right equipment for your business.

Specifications
Barcode Reading
1D, 2D
Scan Angle
40º(h)x32º(v)
Equipment
Box dimensions, mm
215*75*100
Interface cable
USB
Scan Range
13 MIL
40-170 mm
5 MIL
30-90 mm
Minimum Scan Resolution
3.9 MIL
Housing
Overall dimensions (WxDxH), mm
190*65*55
Weight
125 gr
Technical parameters
Barcode Sensitivity
Tilt ± 65° / Swivel 360° / Deviate ± 60°
Connection type
Wired
Minimum barcode contrast
20%
Number of triggers without breakdowns
5 million
Scan range
Up to 370 mm
Scan speed
100 scans/sec
Scanner resolution
640(h)x480(v)Px
Scanner type
Manual
Scanning element
2D image
Interfaces
Interface
USB HID; USB-COM - emulation; RS232 - optional
Body
Body Material
ABC + PC (plastic + polycarbonate)
Color
Black
Operation parameters
Drop test
Withstands 50 drops from a height of 2 m to a concrete surface or multiple drops from a height of 1.5 m.
Storage temperature
-40°C ~ +70°C
Functionality
Auto Scan
Yes
Honest Sign Support
Yes
Recognition of barcodes from complex surfaces
Yes
Sound and visual indication
Yes
Support EGAIS
Yes
Supported 1D Barcodes
UPC; EAN; Code128; Code 39; Code 93; Code11; Matrix 2 of 5; Interleaved 2 of 5; Codabar; MSI Plessey; GS1 DataBar; China Post; Korean Postal
Supported 2D Barcodes
PDF417; MicroPDF417; data matrix; Maxicode; QR code; MicroQR; Aztec; Hanxin
Performance parameters
Resistance to external influences
IP54
Warranty
3 years
Operating parameters
Operating temperature
-20°C ~ +40°C
Options
Packages
Scanner, USB type A cable (205 cm), Manual, Warranty card, Packaging
Scanner Features
Illumination
Antireflected, 3500K LED
Functional parameters
Application areas
For 1C, For alcohol, For marking, For a pharmacy, For perfumes, For EGAIS, For a store, For marking shoes, For cigarettes, For a warehouse, For an honest sign, For EVOTOR, Industrial
Functioning parameters
Analogues of manufacturers
datalogic; honeywell; Zebra; Newland; CipherLab
